Scantronic DET-2R-PIR: Two-Way Pet Tolerant PIR Detector – Grade 2

Full Description

Reliable Wireless Pet Tolerant PIR Detector By Scantronic

The Scantronic DET-2R-PIR is a high-performance two-way wireless Passive Infrared (PIR) detector designed for effective indoor movement detection within Scantronic Secure Radio (SSR) intruder alarm systems. This Grade 2 certified detector offers reliable coverage in a fan-shaped area up to 12 meters, while its pet tolerant feature minimizes false alarms in environments with animals. With advanced two-way communication, true signal encryption, and convenient remote management, the DET-2R-PIR provides a secure and flexible solution for modern security needs.

Key Features of the Scantronic DET-2R-PIR:

• Passive Infrared (PIR) Technology: The DET-2R-PIR detects movement based on changes in body heat within a fan-shaped area, providing reliable coverage up to 12 meters in radius.
• Two-Way Wireless Communication: Uses Scantronic Secure Radio (SSR) technology for advanced two-way communication, ensuring robust signal transmission, constant supervision, and efficient event reporting.
• Pet Tolerant: Specifically designed to ignore the presence and movement of pets, significantly reducing the likelihood of false alarms in homes or businesses with animals. Pet tolerance can be wirelessly enabled or disabled, offering flexible security management based on your needs.
• Grade 2 Certified: Compliant with EN 50131 Grade 2 standards, making it suitable for professional security installations requiring a higher level of performance.
• True Signal Encryption (AES128): Features market-leading cybersecurity with true signal encryption to protect against signal interception, jamming, and manipulation, ensuring secure communication.
• Over-the-Air Updates: Scantronic DET-2R-PIR supports remote firmware updates, which helps to future-proof the device and reduces the need for costly and time-consuming onsite visits.
• Optimised Battery Life: Shortened device response times and SSR transmission acknowledgement functionality intelligently extend battery life by up to 66%, using readily available standard AA batteries.
• Rapid Event Notification: Ensures quick communication of any detected movement to the control panel, reducing response times for actual intrusion events.
• Easy Diagnostics: Built-in LED indicators can be remotely activated, simplifying troubleshooting and device identification during installation or maintenance.
• Flexible Mounting: Can be mounted flat against a wall or discreetly in a corner of a room for optimal detection coverage.
• Tamper Protection: Includes robust tamper detection mechanisms to alert the system if the detector is opened or removed from its mounted position.

Technical Specifications:

• Product: Scantronic by Eaton motion sensor
• Catalogue Number: DET-2R-PIR
• Technology Type: Passive Infrared (PIR)
• Connection: Wireless/Radio (Two-Way)
• Detection Type: Volumetric
• Channels: 1
• EN 50131 Grade: Grade 2
• Environmental Class: Class II
• Degree of Protection (IP): IP40 (Suitable for indoor use)
• Mounting Method: Surface (wall or corner)
• Pet Tolerant: Yes (wirelessly configurable)
• Tamper Protection: Yes
• Power Source: Standard AA batteries
• Indication: Optical (LEDs)
• Colour: White
• Dimensions (H x W x D): 115 mm x 55 mm x 55 mm
• Weight: 0.15 kg
• Compliances: EN
• Certifications: CE marking
• See DET-2R-PIR Data Sheet

Benefits:

• Reliable Intrusion Detection: Provides accurate detection of human movement across a significant area.
• False Alarm Reduction: Pet tolerant feature significantly reduces nuisance alarms in homes with animals.
• Enhanced Security: Two-way encrypted communication offers robust protection against cyber threats and tampering.
• Low Maintenance: Extended battery life and over-the-air updates.
• Flexible Deployment: Wireless installation and configurable pet tolerance make it highly adaptable.
• Easy to Manage: Remote diagnostics and simplified installation process.
