Mortice Deadbolt For Heavy-Duty Doors with Door Monitoring

Full Description

Strengthen Door Security and Gain Real-Time Monitoring Capabilities

This electric Mortice Deadbolt For Heavy-Duty Doors with Door Monitoring offers a robust solution for securing high-traffic or high-security entrances. Available in both fail-safe and fail-secure versions, this deadbolt integrates seamlessly with existing mechanical deadbolt locks (13mm square type) and provides an additional layer of security with a built-in door monitoring switch.

Key Features:

• Heavy-Duty Design: Built to withstand demanding applications on heavy-duty doors.
• Compatible with Existing Mechanical Locks: Works seamlessly with 13mm square type deadbolt locks for a simple upgrade.
• Door Monitoring Switch: Provides real-time information on door status (open/closed) for integration with access control systems.
• 12V DC Operation: Requires a 12V DC power supply for operation.
• Fail-Safe or Fail-Secure Option: Choose between fail-safe (unlocked when de-energised) or fail-secure (locked when de-energised) based on your security needs (please specify selection when ordering).
• Durable Construction: Zinc alloy housing ensures long-lasting performance.

Benefits of a Mortice Deadbolt For Heavy-Duty Doors:

• Enhanced Security: The Mortice Deadbolt For Heavy-Duty Doors with Door Monitoring strengthens door security by adding an electronic locking mechanism to existing mechanical deadbolts.
• Real-Time Monitoring: Provides valuable information on door status for improved access control.
• Versatile Application: Suitable for various heavy-duty door applications in commercial, industrial, and institutional settings.
• Flexible Operation: Choice between fail-safe or fail-secure versions caters to specific security requirements.
• Simple Integration: Works seamlessly with existing 13mm square type deadbolt locks.

Ideal Applications:

• Commercial Buildings: Secure entrances to offices, warehouses, and server rooms.
• Industrial Facilities: Enhance security for restricted areas and equipment rooms.
• Institutions: Control access to schools, hospitals, and government buildings.
• High-Traffic Areas: Reinforce security for frequently used entrances.

Technical Specifications:

• Voltage tolerance: ±10%
• Current draw: 120mA (at temperature 20°C)
• Operating temperature: -10~45°C (14 to 131°F)
• Surface temperature: Current temperature ±20% (when powered)
• Bolt status output indicates bolt locked or unlocked status (SPDT rated 3A at 30VDC)
• Horizontal or vertical installation
• Nominal weight: 600g
